The Metal Warehouse Catalog
Every panel, structural member and trim profile we make, with the specifications that decide which one you need.
Start Here
Panel Application Matrix
Nine panels, and what each one is actually for. If you know your roof slope and whether you are covering a roof, a wall, a soffit or a deck, this table picks the panel for you.
| Panel | Roof | Wall | Soffit | Deck | Fence | Min Slope |
|---|---|---|---|---|---|---|
| PBR Panel | Recommended | Recommended | Not recommended | Not recommended | Not recommended | 3/4":12* |
| PBU Panel | Recommended | Recommended | Marginal or special use | Not recommended | Not recommended | 1:12* |
| AG Panel | Recommended | Recommended | Marginal or special use | Not recommended | Not recommended | 3/4":12* |
| 1.5" B-Deck | Recommended | Not recommended | Not recommended | Recommended | Not recommended | 1/4:12 |
| 1.5" Composite Deck | Not recommended | Not recommended | Not recommended | Recommended | Not recommended | n/a |
| 1" Nail Strip SS | Recommended | Marginal or special use | Not recommended | Not recommended | Not recommended | 3:12 |
| 1-3/4" Snap Lock SS | Recommended | Marginal or special use | Not recommended | Not recommended | Not recommended | 2:12 |
| 2" Mech Lock SS | Recommended | Marginal or special use | Not recommended | Not recommended | Not recommended | 1/2:12 |
| 12" Board & Batten | Not recommended | Recommended | Recommended | Not recommended | Not recommended | n/a |
- Recommended
- Marginal or special use
- Not recommended
- Butyl tape sealant required at the lower slopes
Slopes are the minimum we will supply the panel for. If your roof is close to a limit, call us before you order: (903) 465-6699.
Reference
Gauge Guide
Gauge runs backwards: the smaller the number, the thicker the steel.
- 26 ga.
- Most common panel gauge for residential and light commercial. Standard for PBR, PBU, AG, 1" Nail Strip and 12" Board & Batten.
- 24 ga.
- Heavier panel gauge. Standard for 1-3/4" Snap Lock and 2" Mechanical Lock standing seam.
- 22 / 20 / 18 ga.
- Galvanized deck gauges for B-Deck and Composite Deck.
- 16 / 14 / 12 ga.
- Cold-formed structural shapes: C-Purlins, Z-Purlins and Eave Struts.
Reference
Finish Guide
What the coating is, and which products carry it.
- SMP
- Silicone-modified polyester. Standard finish for exposed fastener panels and standard trims, 40-year warranty.
- PVDF (Kynar)
- Premium finish for 1-3/4" and 2" standing seam, 35-year warranty.
- Galvalume (AZ55)
- Unpainted metallic finish for structural deck products and standing seam where specified.
- Red Oxide Primer / Galvanized G90
- Structural member finishes.
The Full Range
Everything Else in the Catalog
Structural Components
- C-PurlinsStandard Cee profile, 4" to 12" web, 12 to 16 gauge.
- Z-PurlinsNestable flanges for continuous multi-bay spans.
- Eave StrutsCut to your roof pitch, single slope, double slope and high eave.
- Fabricated Structural / PEMBColumns, rafters, girts, trusses and welded components to your drawing.
Trim & Flashing
53 trim and flashing profiles with part numbers and dimensions, from ridge cap and eave trim to gutters, valleys, jamb caps and angles, plus panel-specific trims for PBR, PBU and standing seam.
Browse the trim catalog →Colors & Finishes
17 stock colors: 14 standard and 3 premium, in Sherwin-Williams SMP with a 40-year paint warranty. PVDF and unpainted Galvalume are available on selected profiles.
See the color range →Accessories
Fasteners, closures, sealants, seal tape, insulation, roof jacks, pipe flashings and walk-through doors. The parts that finish the job.
See accessories →More panel profiles
We also stock these profiles. Call us for current specifications and availability.
Common Questions
Choosing the Right Product
Which metal panel can I use on a low-slope roof?
It depends how low. Our PBR and AG panels run down to a 3/4 inch in 12 slope with butyl tape sealant, and PBU down to 1:12. In standing seam, the 2 inch Mechanical Lock goes to 1/2:12 when it is double-locked, the 1-3/4 inch Snap Lock to 2:12, and the 1 inch Nail Strip needs 3:12 or steeper. The full table is on this page. Call (903) 465-6699 with your slope and we will confirm the right panel.
Which panels can be used for soffit?
The 12 inch Board and Batten panel is made for wall and soffit work. PBU and AG panels can be used for soffit as a marginal or special-use application. PBR and our standing seam panels are not recommended for soffit.
What gauge should my metal panels be?
26 gauge is the most common panel gauge for residential and light commercial, and it is the standard for PBR, PBU, AG, 1 inch Nail Strip and 12 inch Board and Batten. Our 1-3/4 inch Snap Lock and 2 inch Mechanical Lock standing seam panels are 24 gauge. Structural deck comes in 22, 20 and 18 gauge, and cold-formed structural shapes in 16, 14 and 12 gauge.
What is the difference between SMP and PVDF?
SMP (silicone-modified polyester) is our standard painted finish, carrying a 40-year paint warranty across 17 stock colors. PVDF, also known as Kynar, is the premium coating available on our 24 gauge standing seam panels, with a 35-year warranty and better long-term color and chalk resistance. Both are Sherwin-Williams coil coatings.
Not Sure Which Product You Need?
Tell us the building, the slope and the look you are after, and we will tell you which panel, trim and framing package fits. We roll-form in Sherman and cut to your length, so most orders are ready fast.
