About Purlins & Eave Struts
Purlins and eave struts are the secondary framing that ties a metal building together and gives the roof and wall panels something to fasten to. Metal Warehouse Inc. manufactures C and Z purlins and eave struts in 12, 14 and 16 gauge, primed or galvanized, and stocks the clips and chairs that go with them, sized to your building.
Purlins are the horizontal members that run between the main frames to support roof and wall sheeting; eave struts are the special purlins that sit at the roof-to-wall junction and carry both. Metal Warehouse Inc. manufactures grade 55 purlins in both C and Z profiles in 12, 14 and 16 gauge, with web depths from 4 inch to 12 inch and a choice of red oxide primer or galvanized G90 finish. Z-purlin flanges are nestable, so they lap at the frame for continuous spans. We also make eave struts from 4 inch to 12 inch nominal in single slope, double slope and high eave profiles, and stock the purlin clips and chairs that connect them - so you can frame a complete secondary structure from one supplier.
The Details
Purlins Specifications
| Profiles | C-purlin and Z-purlin, web depths 4″, 6″, 8″, 10″ and 12″ |
| Flange Depths | C-purlin 2″ to 4″; Z-purlin 2″ to 3-1/2″, nestable for lapped connections at the frame |
| Gauge / Grade | 12, 14 and 16 gauge, grade 55 |
| Punch Slots | 5/8″ x 1″ |
| Eave Struts | 4″ to 12″ nominal web depth in 12, 14 and 16 gauge; 4″ flanges standard, or 3″ top / 5″ bottom; single slope, double slope and high eave profiles |
| Connectors | Purlin clips and purlin chairs stocked |
| Finish | Red oxide primer or galvanized G90 |
| Availability | Common sizes stocked; long runs and specials sourced in under a week |
Stock Status
Purlins: In Stock vs Special Order
What we keep on the shelf versus what we bring in for you. In-stock ships fast; special-order items we source, typically in under a week.
In Stock Now (13)
- 10"X2.125"X2.375" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 10"X3.125"X3.375" Zpurlin 12 GAUGE Red Oxide GRADE 55
- 10"X3.125"X3.375" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 10"X2.625"X2.875" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 12"X2.125"X2.375" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 12"X2.625"X2.875" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 6"X2.125"X2.375" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 8"X2.125"X2.375" Zpurlin 12 GAUGE Red Oxide GRADE 55
- 8"X2.125"X2.375" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 8"X3.125"X3.375" Zpurlin 12 GAUGE Red Oxide GRADE 55
- 8"X3.125"X3.375" Zpurlin 14 GAUGE Red Oxide GRADE 55
- 8"X2.625"X2.875" Zpurlin 12 GAUGE Red Oxide GRADE 55
- 8"X2.625"X2.875" Zpurlin 14 GAUGE Red Oxide GRADE 55
Available by Special Order
Plus 164 more purlins sizes and specs available by special order, typically sourced in under a week. See every size on the full product list, or tell us what you need.
In the Field
Common Applications
Contractors and fabricators across North Texas and Southern Oklahoma put purlins to work on jobs like these:
- Secondary roof and wall framing for metal buildings
- Pre-engineered and weld-up building kits
- Re-roof and retrofit purlin runs
- Eave struts at the roof-to-wall junction
- Agricultural and equipment shelters
Why Metal Warehouse
Why Choose Purlins
Matched secondary framing - purlins, eave struts, and clips together
Primed and paint-ready, or galvanized G90 where the run needs it
Pitch-selectable eave struts so the roof line comes out right
Cut and stocked for local builders, not shipped in from out of state
The Range
Which Member Do You Need?
Three products sit under this heading. Each has its own dimensions, gauges and finishes.
Get a Quote for Purlins
Tell us the shapes, sizes, gauges, and quantities you need. We stock most structural steel and can source the rest in under a week. Serving contractors throughout North Texas and Southern Oklahoma from our Sherman warehouse.
