About 1.5" Composite Deck
1.5" Composite Deck
1.5 inch Composite Deck is the structural floor deck for composite concrete slabs. The panel is embossed so it locks mechanically into the concrete poured over it, and the deck and the slab then act as one structural unit. Metal Warehouse Inc. supplies it cut to order for contractors across North Texas and Southern Oklahoma.
Composite Deck looks like B-Deck at a glance: the same 1-1/2 inch rib at 6 inch centers across 36 inches of coverage, and the same nesting side lap. The difference is the embossment. Small raised patterns are rolled into the rib walls so that when concrete is poured over the deck it grips the steel instead of simply resting on it. That mechanical interlock is what makes the floor composite, letting the steel deck act as the tension reinforcement for the slab rather than as a form that gets left behind. If you only need something to pour on and then forget about, B-Deck is the cheaper answer. If the deck has to carry load with the slab, this is the panel.
Panel Data
Composite Deck Technical Specifications
Roll-formed on-site in Sherman, TX and cut to your exact length.
| Coverage Width | 36 inches |
| Rib Height | 1-1/2 inches |
| Rib Spacing | 6 inches on center |
| Embossment | Embossed for mechanical interlock with concrete |
| Side Lap | Nesting side lap |
| Standard Gauges | 22, 20 and 18 gauge galvanized |
| Finish | G-60 galvanized standard; G-90 galvanized special order |
| Standard Lengths | Cut to order |
Where It Fits
Common Applications for Composite Deck
Contractors, builders, and owner-builders across North Texas and Southern Oklahoma use Composite Deck across a range of projects:
- Composite concrete floor systems
- Mezzanine floor systems in warehouses and industrial buildings
- Heavy-load decks where the slab and deck work together
- Structural floor systems in multi-story construction
- Elevated platforms and equipment floors
The Advantages
Why Choose Composite Deck
Embossed for positive concrete interlock, so the floor performs as a composite section
Same 36 inch coverage and nesting side lap as our B-Deck, so it lays out the same way
Three gauges stocked, 22, 20 and 18, to match the span and load you are designing for
Cut to order, so panels arrive at length with no field cutting waste
Color & Protection
Available Finishes & Coatings
Exact finish options vary by profile - call us to confirm what is available for Composite Deck.
Silicone-modified polyester, our standard painted finish. 40-year paint warranty, 17 stock colors.
Premium painted finish on our 24 gauge standing seam panels. 35-year warranty, superior color and chalk resistance.
Unpainted zinc-aluminum alloy coating. Available on structural deck and 24 gauge standing seam.
G-60 standard or G-90 special order on deck products; G90 on structural framing members.
Common Questions
Composite Deck FAQs
Can you cut Composite Deck panels to length?
Yes. We roll-form most of our panel profiles on-site at our Sherman, TX facility and cut them to your specified length, so you get an exact fit with minimal waste and no freight damage. Most orders are ready in 1-5 business days.
What colors and finishes are available for Composite Deck?
Painted panels use Sherwin-Williams SMP with a 40-year paint warranty, in 17 stock colors: 14 standard and 3 premium. Our 24 gauge standing seam profiles are also available in Galvalume or PVDF (Kynar). Exact options vary by profile, so call us to confirm what is available for Composite Deck.
Do you deliver Composite Deck panels?
Yes - we deliver throughout North Texas and Southern Oklahoma. Delivery cost depends on your location and order size, and you are welcome to pick up at our Sherman, TX yard. Call (903) 465-6699 for a delivery quote.
Get an Estimate for Composite Deck
Tell us your panel length, quantity, color, and gauge. We roll-form most panels on-site and can have material ready in 1-5 business days.
